| Video And Audio |
| IP Video Input |
| 8-ch |
| Up to 4 MP resolution |
| Incoming Bandwidth60 Mbps |
| Outgoing Bandwidth60 Mbps |
| HDMI Output1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Video Output ModeHDMI/VGA simultaneous output |
| Decoding |
| Decoding FormatH.265+/H.265/ H.264+/H.264 |
| Recording Resolution4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
| Synchronous Playback8-ch |
| Decoding Capability4-ch@1080p (25 fps), 2-ch@4 MP (25 fps) |
| Stream TypeVideo, Video & Audio |
| Network |
| Remote Connection16 |
| Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™ |
| Network Interface1, RJ-45 10/100Mbps self-adaptive Ethernet interface |
| Auxiliary Interface |
| SATA1 SATA interface |
| CapacityUp to 6TB capacity for each disk |
| Alarm In/OutN/A |
| USB InterfaceRear panel: 2 × USB 2.0 |
| General |
| Power Supply12 VDC, 1.5 A |
| Consumption≤ 10 W |
| Working Temperature-10 to +55º C (+14 to +131º F) |
| Working Humidity10% to 90% |
| Dimension (W × D × H)265 × 225 × 48 mm (10.4" × 8.9" × 1.9") |
| ≤ 1 kg (2.2 lb) |
| Certification |
| FCCPart 15 Subpart B, ANSI C63.4-2014 |
| CEEN50130-4, EN 61000-3-2,EN 61000-3-3 |
